直销JP22干粉砂浆喷涂机 石膏砂浆喷浆机

         JP22是我公司引进德国技术制造的一款小型机械，设有水泵与水计量功能；具有自动搅拌、泵送、粘结、喷涂联合作业功能，适应各类不同特性与不同用途预拌干混砂浆施工，包括内外墙砂浆、保温砂浆、自流平砂浆、粘接砂浆、修补砂浆等；设置压力控制保护机构，实现远程控制操作；模块式结构，拆装方便，结构紧凑；体积小，移动方便，适应狭窄空间使用。

     JP22 is small machine introduced German technology. It sets water pump and water measuring function. It has the combined function of automatic mixing, pumping, bonding, plastering. It’s suitable for construction of different characteristics and use of dry ready-mixed mortar including internal and external wall mortar, thermal insulation mortar, self-leveling mortar, bonding mortar, repairing mortar etc. It sets the pressure controlling protection mechanism and achieves the remote control. With modular and compact structure, it's easy to dissemble. Due to its small volume, it's easy move and adapt for use in narrow spaces.

标准配置Standard equipment

混合区料斗Mixing hopper

泵设备Pump equipment      Wenggong D40

水压泵Water pressure pump

齿轮马达Gear motor  RF57-Y4KW

带快速连接器空气管Air tube with fast connector  ID:￠13  Length:10m

防震压力计总成    Shockproof pressure gage assembly  YN60-6Mpa

输浆管Delivery hose     GB/T3683 25-1-W.P或

                                   GB/T3683 32-1-W.P.9Mpa  Length:10m

带有气源支持喷枪Spraying gun with air support（配喷嘴with spraying nozzle）

水量电枢控制集成Water volume armature control integration  LZS-15 100-1000L/h

工具箱Tool box

操作说明书Operating instruction

   JP22型砂浆喷涂机技术参数

   Technical parameters of JP22 Mortar plastering machine

   电源Supply power                                                 400V  50Hz

   电机功率Motor power                                             4.0  2.2kw

   **大颗粒尺寸Maximum grain size                             4mm

   排量Output                                                         25L/min

   输送压力Delivery pressure                                      40bar

   水平输送距离Horizontal delivery distance                  40m

   垂直输送距离Vertical delivery distance                      15m

   送料斗容量Hopper volume                                       50L

   重量Net weight                                                    185kg

   外型尺寸Dimension (L×W×H)                                 1200*660*1100mm

 注：以上数据只作参考，因选用砂浆的理化性能差别，其产生的各项数值也不相同。

Note: The above figures are only for reference, due to differences in physical and chemical properties of selected mortar, its each value is different accordingly.
