| 材质 | 金刚石 |
|---|---|
| 产地 | 郑州 |
| 工艺 | 烧结或电镀 |
| 规格 | 75*25*20*5*3 |
| 厚度 | 10mm |
| 类型 | 多款供选 |
| 粒度 | 60#-5000#（目） |
| 适用范围 | 多用途 |
| 形状 | 异形 |
| 适用行业 | 金属加工 |
| 结合剂 | 树脂，陶瓷，电镀金刚石 |
| 发货期限 | 3天 |
| 品牌 | 锐捷 |
| 加工定制 | 是 |
1A8型
结合剂：B.M.V
| D | T | H | X |
| 6 | 15 20 | 3 | 2 |
| 8 | 15 20 | 3 5 | 2 |
| 9.5 | 15 20 | 5 | 2 |
| 10 | 15 20 | 5 | 2 |
| 12 | 15 20 | 6 | 2 |
| 15 | 15 20 | 6 8 | 2 |
| 17 | 15 20 | 6 8 | 2 |
| 19 | 15 20 | 6 8 | 2 |
| 21 | 20 25 30 | 8 10 | 2 |
| 25 | 20 25 30 | 8 10 | 2 |
| 30 | 20 25 30 | 10 12 | 2 |
| 32 | 20 25 30 | 10 12 | 2 |
| 35 | 20 25 30 | 10 12 | 2 |
| 40 | 20 25 30 | 10 12 | 2 |
| 45 | 20 25 30 | 12 20 | 3 |
| 48 | 20 25 30 | 12 20 | 3 |
| 50 | 20 25 30 | 12 20 | 3 |
| 60 | 20 25 30 | 12 20 | 3 |
| 75 | 20 25 30 | 20 | 3 |
| 80 | 20 25 30 | 20 | 3 |
| 100 | 20 25 30 | 20 | 45 |
| 125 | 20 25 30 | 20 32 | 45 |
| 150 | 20 25 30 | 32 | 45 |
| 175 | 15 20 | 32 | 6 |
| 200 | 15 20 | 32 75 | 6 |
| 250 | 15 20 40 | 75 127 | 10 |
| 300 | 20 32 40 | 127 203 | 10 |
| 350 | 20 25 30 40 | 127 203 | 10 |
| 400 | 20 30 40 | 203 | 10 |
| 450 | 20 30 40 | 203 | 10 |
| 500 | 20 30 40 | 203 305 | 10 |
| 600 | 20 30 40 | 203 305 | 10 |
| 750 | 20 30 40 | 203 305 | 10 |
????????
1A1型 ??? ???????????1EE1型 ?????????????????
结合剂：B.M.V
| 型号 | D | T | H | X | X1 |
| 1A1 | 114 | 20 | 16 | 2.5 | — |
| 1EE1 | 114 | 22 | 16 | 2.5 | 3 |
1A1/T2型
结合剂：B.M.V
| D | T | H | X |
| 100 | 15 20 | 20 | 6 |
| 125 | 15 20 | 20 32 | 6 |
| 150 | 15 20 | 32 | 6 |
| 175 | 15 20 | 32 | 6 |
| 200 | 15 20 40 | 32 75 | 6 |
| 250 | 20 30 40 | 75 127 | 10 |
| 300 | 20 30 40 | 127 203 | 10 |
| 350 | 20 30 40 | 203 | 10 |
| 400 | 20 30 40 | 203 | 10 |
| 450 | 20 30 40 | 203 305 | 10 |
| 500 | 20 30 40 | 203 305 | 10 |
| 600 | 20 30 40 | 203 305 | 10 |
| 750 | 20 30 40 | 305 | 10 |
| 900 | 20 30 40 | 305 | 10 |
| 1000 | 20 30 40 | 305 | 10 |
| 1200 | 20 30 40 | 305 | 10 |
1A1/T3型
结合剂：B.M.V
| D | T | H | X |
| 125 | 60 120 | 配轴 | 5 |
| 150 | 60 120 | 5 | |
| 175 | 60 120 | 5 | |
| 200 | 60 120 | 5 | |
| 250 | 60 120 150 | 10 | |
| 300 | 60 120 | 10 | |
| 350 | 60 120 150 200 | 127 203 | 10 |
| 400 | 60 120 150 200 | 127 203 | 10 |
| 450 | 60 120 150 200 | 203 | 15 |
| 500 | 60 120 150 200 | 305 | 15 |
| 600 | 60 120 150 200 | 305 | 15 |
| 750 | 60 120 150 200 | 305 | 15 |
